OptimusS is a compact batch portable data terminal designed for retail and light warehouse data collection applications, including inventory and stocking.

Put Metrologic’s OptimusS right in your pocket and take it wherever data collection needs take you. This stylish batch portable data terminal (PDT) combines powerful features with easy-to-use software to get up and running in no time. The OptimusS enables users to quickly scan and store their product information. After data collection is done, simply drop the unit into its cradle and send the data back to the host to keep information up-to-date and accurate. Each OptimusS comes with the Optimizer software package to facilitate application development. This graphically-oriented program allows even
computer beginners to quickly and easily setup the applications they wish to run on their PDT. There are also several simple utilities for uploading and downloading of data. The entire software suite is designed to make PDT application development a painless process. Besides great software, the OptimusS comes with a long list of other features. The OptimusS comes with 2MB RAM to accommodate users with
larger inventory. Never worry about switching batteries again, either. The rechargeable battery that
comes with every OptimusS has a long battery life, allowing approximately 100 hours of scanning
before needing to be recharged. The battery is also Lithium Ion, so users don’t need to worry about it wearing out any time soon. All these features and the excellent laser bar code scanning you’ve come to expect from Metrologic products make the OptimusS optimal for all your data collection needs.

• LCD display with backlight and adjustable font
• Small form factor
• Cradle communicates RS232 and USB
• Fully charged battery lasts approximately 100 hours
• Several Programming Options (Optimizer, BASIC, C)
• Easy to view screen to accommodate different users and environments
• Same feature set as bulkier units in a lighter, easier to handle package
• One cradle does both, so a simple cable swap gives users quick-change ability
• Minimizes customer down time; speeds up the inventory process
• Accommodates different levels of programming skills from beginner to advanced

OptimusS Quick Specs

Depth of Scan Field: 20 mm - 222 mm (0.75” - 8.75”) for 0.33 mm (13 mil) bar codes
Width of Scan Field: 290 mm (11.4”) @ 222 mm (8.75”)
Scan Speed: 100 scan lines per second
Minimum Bar Width: 0.127 mm (5 mil)
Dimensions: Terminal: 137 mm H x 28 mm D x 55 mm W (5.4” H x 1.1” D x 2.2” W)
Cradle: 58 mm H x 110 mm D x 92 mm W (2.3” H x 4.3 ” D x 3.6 ” W)
Visible Laser Diode: 650 nm
Weight: 140 g (4.9 oz) - including batteries
Shock resistance: 1.2 m (4’) drop onto concrete
Battery Operation: Li-ion
Data Memory: 2MB SRAM
Resolution: 8 lines x 16 characters (max), 4 lines x 12 characters (min)

OPERATIONAL
System
CPU 16-bit CMOS, low power consumption
Program Memory 1 MB flash ROM
Data Memory 2 MB SRAM
Display LCD - 100 x 64 pixels, back-lit
Resolution 8 lines x 16 characters (max), 4 lines x 12 characters (min)
Keypad 21 rubber keys; alpha/numeric, function, scanner
Indicators Buzzer - programmable audible indicator (1 KHz - 4KHz)
LED - Dual-color, programmable green and red
Communication (Unit) Cradle IR
Communication (Cradle) RS232, USB
Application Development Windows-based Optimizer; optional C & BASIC compilers

MECHANICAL
Weight 140 g (4.9 oz) - including batteries

ELECTRICAL
Battery Operation Li-ion
Battery Backup 3.7V, 7.0mA hours, rechargeable lithium battery
Operation Over 100 hours
EMC regulation FCC Class A, CE and C-Tick approved

ENVIRONMENTAL
Operating Temperature -20°C to 55°C (-4°F to 131°F)
Storage Temperature -30°C to 60°C (-22°F to 140°F)
Humidity 5% to 95% relative humidity, non-condensing
Shock resistance 1.2 m (4’) drop onto concrete

SCAN PERFORMANCE
Laser Scanner
Visible Laser Diode 650 nm
Minimum Bar Width 0.127 mm (5 mil)
Width of Scan Field 290 mm (11.4”) @ 222 mm (8.75”)
Depth of Scan Field 20 mm - 222 mm (.75” - 8.75”) for 0.33 mm (13 mil) bar codes
Scan Speed 100 scan lines per second
Print Contrast 35% minimum reflective difference
Bar Code Minimum Element
0.132 mm (5.2 mil)
0.190 mm (7.5 mil)
0.264 mm (10.4 mil)
0.330 mm (13 mil)
0.495 mm (19.5 mil)

Specifications are subject to change without notice.  All product and company names are trademarks, service marks or registered trademarks of their respective owners.
