MS3780 Fusion

Metrologic’s Fusion combines omnidirectional and single-line laser bar code scanning into a lightweight, ergonomic hand-held form factor. The 20-line scan pattern provides superior scanning over existing single-line hand-held scanners making Fusion ideal for medium-volume retailers including specialty stores, pharmacies, liquor stores, and convenience stores. An adjustable stand with 50° of tilt and three
locking positions provides flexibility for the user to position the scanner for individual comfort and
optimal performance. Stabilized with a weighted metal base, the stand may also be hard-mounted to counters or walls.
Fusion also includes CodeGate®, a Metrologic patented feature used in the highly successful Voyager® Series. An integrated infra-red (IR) sensor automatically activates the laser when a bar code is present. The user then properly aligns the bar code before pressing the button, transmitting the data to the host. This feature provides the ability to pass over other bar codes, selecting only the required code. No other scanner offers this much control. Standard features such as Flash ROM, MetroSelect® and MetroSet2® programming, and user replaceable cables protect your investment by enabling Fusion to grow with you and your application requirements. Fusion™ is an affordable hand-held omnidirectional laser scanner with single-line capability that increases retail checkout system efficiency with its automatic in-stand operation, optionally integrated EAS, and industry-leading scan performance.

OPERATIONAL

Light Source Visible Laser Diode 650 nm
Laser Power 1.1 mW (peak)
Decode Capability Autodiscriminates all standard 1D bar codes, including RSS-Expanded,
RSS-14 and RSS-14 Limited; for other symbologies call Metrologic
System Interfaces RS232, Keyboard Wedge, Stand Alone Keyboard,
IBM 468x/469x, USB, OCIA
Number Characters Read Up to 80 data characters
Beeper Operation 7 tones or no beep
Indicators Blue = laser on, ready to scan
White = good read

MECHANICAL

Length (scanner only) 189 mm (7.44”)
Width (scanner only) 65 mm (2.56”)
Height (scanner only) 73 mm (2.88”)
Weight (scanner only) 195 g (6.9 oz)
Termination 10 position modular RJ45 connector
Cable Standard 2.1 m (7’) straight; optional 2.7 m (9’) coiled for other
cables call Metrologic


SCAN PERFORMANCE

Depth of Scan Field 25 mm - 279 mm (1” - 11”) for 0.33 mm (13 mil) bar code
(programmable) at default setting
Width of Scan Field 30 mm (1.2”) @ 25 mm (1.0”); 150 mm (5.9”)
@ 280 mm (11.0”)
Scan Speed 1,333 scan lines/sec, omnidirectional; 67 scan lines/sec, single-line
Scan Pattern 5 fields of 4 parallel lines omnidirectional; or button activated
single line
Number of Scan Lines 20 (omnidirectional); or 1 (single-line)
Minimum Bar Width 0.127 mm (5.0 mil)
Print Contrast 35% minimum reflectance difference
Roll, Pitch, Yaw 360°, 60°, 60°

ELECTRICAL

Input Voltage 5 VDC + 0.25 V
Power 1.375 W
Operating Current 275 mA typical @ 5 VDC
DC Transformers Class 2; 5.2 VDC @ 650 mA
Laser Class Class 1; IEC60825-1:1993/A1:1997+A2:2001
Class 1; EN60825-1:1994/A11:1996+A2:2001
EMC FCC, ICES-003 & EN55022 Class A

ENVIRONMENTAL

Operating -20°C to 40°C (-4°F to 104°F)
Storage Temperature -40°C to 60°C (-40°F to 140°F)
Humidity 5% to 95% relative humidity, non-condensing
Light Levels Up to 4842 Lux (450 footcandles)
Contaminants Sealed to resist airborne particulate contaminants
Ventilation None required
Drop/Shock Withstands multiple 1.5 m drops
