The IT4600 area imager combines the versatility of area imaging with the speed and cost of linear scanning for retail and commercial applications. Powered by Adaptus™ Imaging Technology 5.0, the IT4600 is full featured, fast, and cost effective.
Today’s demanding retail and commercial applications will involve much more than linear bar codes. EAN·UCC composite codes are beginning to appear in food stores; PDF codes are used for age verification in restricted item sales; and postal bar codes are used to sort mail. The omni-directional reading capability of the IT4600 allows fast and easy reading of all these codes. Simply point and shoot. There’s no need to align a scan line, or wait for a raster beam to open up.Whether capturing a signature as proof of delivery, taking a picture for identification, or electronic data storage, image capture is a mainstream requirement and an important part of current and future solutions. Equipped with Adaptus™ Imaging Technology 5.0, the IT4600 provides best-in-class image quality and image transfer speed, all at very economical imaging for best-in-class image quality and image transfer speed, all at very economical prices.
The IT4600 is now easier to use under the most challenging conditions with Adaptus Imaging Technology 5.0; and with no moving parts, the IT4600 is as durable as it is versatile.
Performance
Illumination LEDs: 626nm +30nm
Aiming: Green LED Aimer: 526nm +30nm
Image: VGA, 752x480. Binary, TIFF, or JPEG output.
| Working Range:Near |
Far |
| 8.3 mil Linear (.021cm)3.5 in. (8.9cm) |
7.5 in. (19.1cm) |
| 13 mil UPC (.033cm)2.1 in. (5.3cm) |
13.1 in. (33.3cm) |
| 6.6 mil PDF417 (.017cm)4.4 in. (11.2cm) |
6.1 in. (15.5cm) |
| 10 mil PDF417 (.025cm) 3.0 in. (7.6cm) |
8.9 in. (22.6cm) |
| 15 mil Data Matrix (.038cm)2.3 in. (5.8cm) |
10.1 in. (25.7cm) |
| 35 mil MaxiCode (.089 cm) 2.0 in. (5.1cm) |
12.9 in. (32.8cm) |
T4600 SF
| Working Range: Near |
Far |
| 7.5 mil Linear (.019cm) 2.5 in (6.4cm) |
6.4 in. (16.3cm) |
| 13 mil UPC (.033cm) 2.0 in. (5.1cm) |
8.8 in. (22.4cm) |
| 6.6 mil PDF417 (.017cm) 2.8 in. (7.1cm) |
5.9 in. (15.0cm) |
| 10 mil PDF417 (.025cm)2.2 in. (5.6 cm) |
7.5 in. (19.1cm) |
| 15 mil Data Matrix (.038cm)1.8 in. (4.6cm) |
7.4 in. (18.8cm) |
| 15 mil QR Code (.025cm)1.7 in. (4.3cm) |
5.4 in. (13.7cm) |
Skew Angle: +40o
Pitch Angle: +40o
Motion Tolerance: 4 in. ( 10cm) per second
Mechanical/Electrical
Dimensions
Length: 5.3 in. (13.5 cm)
Height: 6.2 in. (15.7 cm)
Width: 3.2 in. (8.1 cm)
Weight: 6.5 oz. (184.3 g)
Housing: UL 94V0 grade
Power Requirements: 4.0- 14VDC at imager
Power Supply
Noise Rejection: Maximum 100mV peak to peak, 10 to 100 kHz
Sealing: IP41 (Water and Dust Resistant)
Temperature
Operating: +32oF to +122oF (0oC to +50oC)
Storage: -40oF to 158oF (-40oC to +70oC)
Humidity: 0 to 95%, non-condensing
Mechanical Shock: Operational after 50 drops from 6 ft. (1.8 m) to concrete
Ambient Light: 0 to 100,00 lux (full sunlight)
ESD Protection: Functional after 100 15kV discharges
Vibration: Withstands 5G peak from 22 to 300 Hz
Agency: FCC Class B, CE EMC Class B, CE Low Voltage Directive, IEC60825-1 LED Safety: Class 1, UL, cUL listed, TÜV,Sunrise Compliant
Laser Classification
Laser Aimer Model Only:
Class 2 under 21 CFR 1040.10 and 1040.11
1mW max output, 650 nM, EN60825-1: 1994+A11+A2
MTBF: per MIL-HDBK-217F Ground Benign exceeds 70,000 hours
Symbologies
2 Dimensional: PDF417, MicroPDF417, MaxiCode, Data Matrix, QR Code, Aztec, Aztec Mesas, Code 49, and EAN•UCC Composite
Linear:
Codabar, Code 39, Interleaved 2 of 5, Code 93, Code 128, UPC, EAN, RSS, Codablock F, and BC412 *available to licensed users
Postal ( SR/SF Only): Australia Post, Postnet, Planet Code, British Post, Canadian Post, Japanese Post, KIX (Netherlands) Post
OCR Fonts (SR/SF Only): OCR-A, OCR-B
Interfaces:
All popular PCs and terminals via keyboard wedge, keyboard replacement/direct connect, USB, TTL level RS-232, wand emulation (primary interface only) mode, TTL level Serial Wedge, and IBM 46XX retail terminals.
HHLC non decoded laser output in 4600SR000 model.
True RS-232 in 4600SR030 model.
Warranty: 5 year warranty
